The JLS-D2513-01 Display Driver Board delivers a reliable interface between video sources and LCD panels. Featuring HDMI 1.4 and VGA inputs, dual-channel LVDS output up to 186 MHz, and integrated audio plus backlight driving, it is designed for industrial control, digital signage, and OEM projects where stability and compact integration are essential.
As display technologies evolve across industries, from industrial automation to medical imaging and digital signage, the need for stable and versatile driver boards continues to grow. Buyers increasingly demand boards that not only support multiple input formats but also integrate audio and power management to reduce system complexity. In this context, the Display Driver Board JLS-D2513-01 stands out as a practical solution for system integrators and equipment manufacturers.
HDMI 1.4 and VGA inputs for compatibility with modern and legacy devices.
Dual-channel LVDS output (up to 186 MHz) ensuring smooth, high-definition display performance.
Integrated backlight driver (up to 15 W) with optional customization.
Audio outputs: 3.5 mm headphone jack + 3 W stereo speaker output.
Model: JLS-D2513-01
Power Supply: 12 V DC
Operating Temperature: 0 °C to 50 °C
Storage Temperature: −20 °C to 70 °C
Supports multiple video inputs (HDMI + VGA).
High-frequency LVDS output for HD panels.
Integrated audio and backlight control reduce the need for external modules.
Compact design suitable for industrial and commercial displays.
OEM customization available for large-scale projects.
Maximum operating temperature is 50 °C; extra cooling may be required in hot environments.
Backlight driving power limited to 15 W by default.
Designed for LVDS panels only; not compatible with eDP or MIPI.
Certifications such as CE/RoHS are not listed on the product page and should be confirmed before bulk purchase.
Toroson provides professional display driver solutions with a focus on industrial and commercial markets. With strong OEM/ODM capabilities, technical support, and a stable supply chain, they cater to system integrators and B2B buyers worldwide. Their products are developed with attention to quality control and compliance with international standards, ensuring long-term reliability for global projects.
Q1. Does the board support high-brightness displays?
A: Yes, but only up to 15 W. For higher backlight power requirements, customized versions are available.
Q2. Can the interface layout be customized for OEM projects?
A: Yes. Customization options include connectors, branding, and layout design.
Q3. Is audio output included?
A: Yes. The board has a built-in 3 W stereo amplifier and a 3.5 mm headphone jack.
Q4. What industries typically use this driver board?
A: It is widely used in industrial monitoring, medical displays, commercial signage, and automotive infotainment systems.
Q5. Are samples available for evaluation?
A: Suppliers usually provide samples or small-batch orders for testing before mass deployment.
Core Functionality: HDMI/VGA input, dual-channel LVDS output, integrated audio & backlight control.
Target Applications: Industrial displays, medical equipment, digital signage, transportation systems.
Procurement Guidance: Best suited for B2B buyers seeking compact, reliable, and customizable driver boards. Confirm certifications and cooling needs before deployment in large-scale projects.
