DD080IA-20A
Innolux
The DD080IA-20A 8-inch automotive TFT LCD display is a high-resolution panel engineered for next-generation vehicle systems and industrial embedded applications. Featuring 1200 × 1920 resolution (portrait WUXGA) and in-cell touch technology, this display delivers superior image clarity, fast touch response, and a thinner module structure compared to traditional LCD solutions.
Designed for automotive environments, this module provides stable performance, wide viewing angles, and excellent sunlight readability, making it ideal for smart cockpit displays, infotainment systems, and advanced HMI applications.
Compared with traditional LCD structures, in-cell technology integrates the touch sensor directly into the LCD layer, reducing thickness and improving optical performance and responsiveness—key requirements for modern automotive UI systems.
High Resolution 1200×1920 (WUXGA)
Ultra-sharp display suitable for navigation systems and digital dashboards
High pixel density improves UI clarity and graphical rendering
In-Cell Touch Technology
Touch layer integrated into LCD structure
Faster response and improved optical clarity
Thinner and lighter module design
Automotive-Grade Display Performance
Wide viewing angle for driver and passenger visibility
Designed for dynamic lighting environments inside vehicles
Optimized for long lifecycle automotive applications
High Brightness & Readability
Suitable for in-vehicle use under varying lighting conditions
Supports outdoor readability (depending on backlight configuration)
Standard High-Speed Interface
Typically uses MIPI interface (common for high-resolution panels)
Easy integration with automotive SoC platforms and embedded boards
No. | Item | Specification | Remark |
1 | LCD size | 8.0 inch(Diagonal) | |
2 | Driver element | a-Si TFT active matrix | |
3 | Resolution | 1280 × 3(RGB) × 720 | |
4 | Display mode | Normally Black, Transmissive, AAS | |
5 | Dot pitch | 0.138(W) × 0.138(H) mm | |
6 | Active area | 0.138(W) × 0.138(H) mm | |
7 | Module size | 200.6 x 127.4 mm | Note 1 |
8 | Surface treatment | Anti-Glare | |
9 | Color arrangement | RGB-stripe | |
10 | View direction(Gray Inversion) | 85/85/85/85 (typ) | |
11 | Interface | 1-port LVDS (DE mode only) | |
12 | Backlight power consumption | (4.84)W | Note 2 |
13 | Panel power consumption | 0.75W | |
14 | Weight | 255g(Max.) | |
Note 1:Refer to Mechanical Drawing | |||
Note 2: Base on IL = 65 mA | |||
This 8″ automotive in-cell LCD display module is widely used in:
Automotive infotainment systems
Digital instrument clusters
Smart cockpit displays
Navigation and control panels
Industrial HMI systems
Embedded tablets and smart terminals
| Feature | Benefit |
|---|---|
| Automotive-Grade Panel | Stable supply for vehicle projects |
| High Resolution Display | Suitable for premium UI systems |
| OEM Customization | Touch, brightness, interface tuning |
| Bulk Supply Support | Competitive pricing for volume |
| Engineering Support | Datasheet + integration guidance |
| Long Lifecycle | Ideal for automotive & industrial programs |
Established in 2014, Xiamen Toroson Technology Corporation Limited has been a trusted leader in the manufacturing of TFT LCDs, TFT LCMs, Touch Screens, Controller Boards, and other related electronic components.
Based in Xiamen, China, with additional offices and warehouses in Shenzhen and Hong Kong, Toroson is strategically positioned to provide superior logistics and service to clients worldwide. Toroson's brother company Viete has been an authorized distributor of Innolux for small to medium-sized TFT LCD/LCM and FOG products since 2005.
[Download Full Datasheet] -->
8HD_DD080IA-20A Approval Spec v2.0_20211223.pdf
