VI104VIC06
Toroson
The Toroson VI104VIC06 is a transmissive type color active matrix liquid crystal display (LCD), which uses amorphous thin film transistor (TFT) as switching devices. This panel has a 10.4 inches diagonally measured active display area with resolution 1024 x 768. This product is composed of a TFT LCD panel, polarizers, driver ICs, FPC and PCBA. It offers excellent visual clarity, strong environmental robustness, and integration flexibility.
As a trusted wide temperature LVDS display module supplier, we support B2B buyers with sample orders, bulk procurement, and custom display module solutions to meet different project demands.
No. | Item | Specification | Remark |
1 | LCD size | 10.4 inch(Diagonal) | |
2 | Display Type | Transmissive, a-Si | |
3 | Resolution | 1024X3(RGB)X768 | |
4 | Color arrangement | RGB-stripe | |
5 | Dot pitch | 0.2055(W)×0.2055(H) mm | |
6 | Active area | 210.432(W)×157.824(H)mm | |
7 | Module size | 238.6(W)×175.8(H)×6.5(D) mm | |
8 | Surface treatment | HC | |
9 | Contrast Ratio(light on) | 1000:1(Type) | |
10 | View direction(Gray Inversion) | 80/80/80/80 | |
11 | Interface | LVDS | |
12 | Backlight power consumption | 1.4W(Max.) | |
13 | Panel power consumption | 0.66W(Typ.) | |
14 | Weight | 400g |
High Brightness Display: 1200 cd/m² typical, ensuring readability even under strong ambient light.
Wide Operating Temperature Range: –30 °C to +80 °C, suitable for severe environments.
Stable LVDS Interface: 30-pin FPC with LVDS compatibility for mainstream controller boards.
Efficient Power Consumption: Backlight up to 1.4 W (max), panel typical 0.66 W.
Slim & Robust Design: 6.5 mm module thickness, solid mechanical build.
Consistent Contrast & Viewing Angles: Contrast 1000:1, gray inversion ±80° in all directions.
Precise Imaging: dot pitch 0.2055 mm for sharp, stable image rendering.
With these strengths, the VI104VIC06 module is an ideal component for industrial control panels, automotive displays, embedded systems, POS terminals, medical equipment, and other B2B display applications.
This 10.4-inch LVDS display module is well-suited for:
Industrial control systems and operator panels
Embedded instrumentation and measurement devices
POS terminals, kiosk displays, vending machines
Automotive / vehicle-mounted displays
Medical display systems
Thin industrial devices requiring high readability and temperature resilience
We also provide integrated support — driver boards, backlight modules, interface customizations — to assist B2B clients in accelerating development and deployment.
Looking for a reliable LVDS display solution for your next project?
✅ Request a Sample – Evaluate the VI104VIC06 module with your system
✅ Get a Custom Solution – Share your brightness, interface, or environmental requirements
✅ Request a Bulk Quotation – Tell us your volume and target pricing
[Download Datasheet PDF] | [Request Quote] | [Contact Engineering Team]
10.4inch VI104VIC06 Spec. Toroson 20200220.pdf
