NJ070NA-23A
Innolux
The Toroson 8-inch IPS LCD display module delivers robust visual performance with 1024×768 XGA resolution, 500 cd/m² typical brightness, and a 40-pin LVDS interface. Built with IPS panel technology, it offers wide viewing angles and consistent color reproduction—ensuring reliable readability from multiple directions. Typical 8″ LVDS IPS displays with similar specs deliver wide viewing angles of approximately 85° in all directions.
Designed for industrial, embedded, and OEM applications, this module combines dependable performance, broad temperature support, and easy integration via a standard LVDS interface. It’s well suited for control systems, automation, measurement equipment, medical displays, and other professional products requiring dependable display modules with high visibility.
As a trusted industrial IPS LCD display supplier, we provide bulk procurement, sample orders, OEM/ODM customization, and technical integration support to help procurement and engineering teams successfully adopt this display in their products.
High-Resolution XGA Panel: 1024×768 resolution for crisp text, UI elements, and detailed graphics.
Balanced 500 cd/m² Brightness: Ensures strong visibility in indoor and moderately illuminated environments, making content easy to read without excessive power consumption.
Wide Viewing Angles: IPS panel delivers consistent image quality across a wide field of view, minimizing color shift when viewed from different positions.
Standard 40-Pin LVDS Interface: Low-voltage differential signaling ensures stable, low-noise data transmission between controller boards and display modules.
Industrial & Embedded Ready: Designed for continuous operation in industrial, automation, and embedded systems.
B2B Procurement Flexibility: Supports sample testing, scalable bulk purchase plans, customization options, and long-term supplier relationships.
No. | Item | Specification | Remark |
1 | LCD size | 7.0 inch(Diagonal) | |
2 | Display Format | 1024X3(RGB)X600 | |
3 | Active area | 154.2144(W) × 85.92(H) mm | |
4 | Pixel size | 0.1506(W) × 0.1432(H) mm | |
5 | Surface treatment | Hard Coating | |
6 | Driver element | a-Si TFT active matrix | |
7 | Module size | 164.9(W) ×100(H) ×4.8(D) mm | |
8 | Pixel Configuration | RGB Vertical Stripe | |
9 | Weight | 135(Typ.) | |
10 | View direction(Gray Inversion) | 6 o’clock | |
11 | Interface | LVDS | |
12 | Source Driver IC Gate Driver IC | EK79001AX EK73215BCGA | |
13 | Driving methods | 1+2dot | |
14 | Backlight power consumption | 2.62 W (Typ.) | |
15 | Panel power consumption | 0.4 W (Typ.) , 0.6 W(Max.) |
This 8″ 1024×768 IPS LVDS LCD display module is well suited for a range of B2B applications requiring reliable, wide-angle displays:
Industrial Human-Machine Interfaces (HMIs)
Embedded control panels and automation systems
Medical devices and monitoring equipment
Measurement instruments and test equipment
OEM electronics and custom product series
Point-of-sale (POS) and kiosk displays
With a balance of resolution, brightness, and IPS performance, this display module enables clear, consistent visuals in professional environments.
| Procurement Feature | Benefit |
|---|---|
| Flexible MOQ | Supports sample, small batch, and large volume orders |
| Bulk Pricing Options | Competitive pricing for enterprise volume contracts |
| Customization Services | Interface pinout, brightness tuning, mechanical form factor |
| Sample Evaluation | Test display performance before full production |
| Pre-Shipment QA | Functionality and visual tests with documentation |
| Technical Support | Integration assistance for LVDS and panel timing |
| Long-Term Availability | Supply stability for ongoing OEM/industrial needs |
We help engineering and sourcing professionals secure dependable display components and documentation for deployment in mission-critical systems.
Established in 2014, Xiamen Toroson Technology Corporation Limited has been a trusted leader in the manufacturing of TFT LCDs, TFT LCMs, Touch Screens, Controller Boards, and other related electronic components.
Based in Xiamen, China, with additional offices and warehouses in Shenzhen and Hong Kong, Toroson is strategically positioned to provide superior logistics and service to clients worldwide. Toroson's brother company Viete has been an authorized distributor of Innolux for small to medium-sized TFT LCD/LCM and FOG products since 2005.
[Download Full Datasheet] -->
