Innolux 10.1 Inches IPS TFT LCD Panel EJ101IA-01G 40PIN LVDS Display Module Screen

5 0 Reviews

Innolux LCD Panel EJ101IA-01G supports display 1280(RGB)×800 (WXGA) with aspect ratio of 16:10 (W:H), whose pixels are arranged in RGB Vertical Stripe. As a IPS, Normally Black, Transmissive LCM product, EJ101IA-01G can provide 550 cd/m² display brightness 1000:1 transimissive contrast ratio, 85/85/85/85 (Typ.) viewing angle, best view direction on Symmetry. This LCD adopted 3S10P WLED as it's backlight systerm which was placed as Edge light type and have a working life time of 15K hours, external backlight driver is additionally needed. EJ101IA-01G utilizes LVDS as it's signal inputting systerm, which connected by 40 pins Connector.

Product Characteristics

Quality: Original Grade A
Size: 10.1"
Resolution: 1200 x 800
Aspect Ratio : 16:10
Brightness: 550cd/m2(Typ.)
Interface : 40pin FPC, LVDS
Operating Temp.: -10 ~ 60 °C
Storage Temp.: -20 ~ 70 °C

Price: $ 53

Quantity:
Availability:





Buy Now 12 7 Add to Basket

Model:
EJ101IA-01G
Brand:
Innolux

Product Description

No.	Item	Specification	Remark
1	LCD size	10.1 inch(Diagonal)
2	Driver element	a-Si TFT active matrix
3	Resolution	1280 × 3(RGB) × 800
4	Display mode	Normally black, Trans-missive
5	Dot pitch	0.0565(W) × 0.1695(H) mm
6	Active area	216.96(W) × 135.60(H) mm
7	Module size	229.46(W) ×149.1(H) ×2.50(D) mm	Note 1
8	Surface treatment	HC
9	Color arrangement	RGB-stripe
10	View direction(Gray Inversion)	free
11	Interface	LVDS
12	Backlight power consumption	1.76 W(Typ.)
13	Panel power consumption	0.7W(Typ.)	Note 2
14	Weight	183 g(Typ)
15	Version	1+2line
16	IC	S-IC: ILI6192, G-IC:ILI5801
Note 1:Refer to Mechanical Drawing
Note 2: Power consumption is white pattern
